Generic Disk

Cat. No.: XX-35-0017-004

Added to collection • 1 day ago

Front

Back

Properties

Basic Information

Brand Generic

Size 3.5"

Capacity ~1.44 Mb

Case Properties

Case Color grey / matte

Shutter Properties

Shutter Material metal (silver)

Shutter Engraved No

Write Protection

Write Protection Type sliding

Write Protection Sign none

Label & Density

Label Area Type full + strip

Density Sign embossed

Mold Codes & Markings

Mold Code 1 CS (front)

Mold Code 3 80 (front)

Tooling Mark Visible No

Part Number Details

Part Number 9G1634

Part No. Side back

Part No. Reading Direction right

Part No. Style printed

Part No. Orientation vertical

Part No. Position bottom left

Part No. Color black

Physical Features

HD Hole Style punched

Related Disks

These disks that are closely related to the one above, at first sight sometimes it is difficult to tell whether it is the same disk or not as they differ only in nuances.
This table below helps to compare the disks and summarizes the differences between this disk and the related ones.

Disk	Differences
XX-35-0017-003 ~1.44 Mb	Part Number: XX-35-0017-004: Present XX-35-0017-003: Not present
XX-35-0017-002 ~1.44 Mb	Part Number: XX-35-0017-004: Present XX-35-0017-002: Not present Mold Code 3: XX-35-0017-004: Present XX-35-0017-002: Not present Mold Code 1 Reading Direction: XX-35-0017-004: front XX-35-0017-002: left
XX-35-0017-007 ~1.44 Mb	Part Number: XX-35-0017-004: Present XX-35-0017-007: Not present Rear Marking Text: XX-35-0017-004: — XX-35-0017-007: F5326163E4 Tooling Mark Visible: XX-35-0017-004: No XX-35-0017-007: Yes
XX-35-0017-006 ~1.44 Mb	Part Number: XX-35-0017-004: Present XX-35-0017-006: Not present Mold Code 2: XX-35-0017-004: Not present XX-35-0017-006: Present Mold Code 1 Reading Direction: XX-35-0017-004: front XX-35-0017-006: left Mold Code 3 Reading Direction: XX-35-0017-004: front XX-35-0017-006: right
XX-35-0017-001 F5317975D5 ~1.44 Mb	Part No. Reading Direction: XX-35-0017-004: right XX-35-0017-001: front Part No. Style: XX-35-0017-004: printed XX-35-0017-001: molded Part No. Orientation: XX-35-0017-004: vertical XX-35-0017-001: horizontal Part No. Position: XX-35-0017-004: bottom left XX-35-0017-001: bottom right Tooling Mark Visible: XX-35-0017-004: No XX-35-0017-001: Yes
XX-35-0017-005 G176EM3D ~1.44 Mb	Part No. Reading Direction: XX-35-0017-004: right XX-35-0017-005: front Part No. Orientation: XX-35-0017-004: vertical XX-35-0017-005: horizontal Mold Code 1 Reading Direction: XX-35-0017-004: front XX-35-0017-005: right Mold Code 3 Reading Direction: XX-35-0017-004: front XX-35-0017-005: left Rear Marking Text: XX-35-0017-004: — XX-35-0017-005: MADE IN ENGLAND
